| 포지셔너 |
| |
 |
| |
 Specification |
| Model |
EPR (Rotary type) |
EPL (Linear type) |
| Enclosure |
Exmd II B T6, Exmd II C(H2) T6, IP66, Exia II BT6 |
| Fluids |
Air |
| Input Signal |
4 ~ 20mA DC |
| Split range Application |
4 ~ 12 or 12 ~ 20mA |
| Linearity |
＜ 1.0% |
| Hysteresis |
＜ 0.5% |
| Sensitivity |
＜ 0.5% |
| Operating Temperature |
-20℃ ~ 80℃ |
| Air Piping Connection |
1/4" PT / NPT |
| Conduit Connection |
1/2" PF / NPT |
|
|
|
